| IEEE Standards | IEEE802.11b/g/n, IEEE802.11ac, IEEE802.11ax, IEEE 802.3, 802.3u, IEEE 802.1Q |
| xDSL Standard&Protocol | ITU G.993.2, Up to 17a /30a/35b profile ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP) |
| Interfaces | 3 *10/100/1000 RJ45 LAN Ports 1 *10/100/1000 RJ45 LAN/WAN Port 1 *RJ11 Port 1 * USB 2.0 Port |
| Dimension | 220x141.6x59mm( Wx D x H) |
| Button | WPS&Wi-Fi RST Power |
| External Power Supply | 12V 1.5A |
| Certification | CE、RoHS |
| Protocols | Supports IPv4 and IPv6 |
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0 PPP over ATM (RFC 2364) PPP over Ethernet (RFC2516) IPoA (RFC1577/2225) MER\IPoE (RFC 1483 Routed) Bridge (RFC1483 Bridge) PVC – Up to 8 PVCs |
| DHCP Server | DHCP Server Client List Address Reservation |
| Management | Web Based Conguration(HTTP) Remote management command Line Interface SSL for TR-069 SNMP v1/2c Web Based Firmware Upgrade Diagnostic Tools |
| Advanced Functions | PVC Configuration DSL Settings Routing QoS( Based IP ) |
| Wireless Standard | IEEE 802.11a/n/ac/ax 5GHz IEEE 802.11b/g/n 2.4GHz |
| Bandwidth | 20M/40M/80M |
| Antenna | 4 * 5 dBi Antenna |
| Wireless Speed | 300Mbps at 2.4GHz 1201Mbps at 5GHz |
| Transmission Power | 2.4GHz <20dBm(EIRP) 5GHz <23dBm(EIRP) |
| Wireless Functions | Enable/Disable Wireless Radio Guest network Access Control WPS MESH |
| Wireless Security | None, WPA, WPA2, WPA/WPA2, WPA3 |
| Storage Temperature | -40℃ ~ 70℃ |
| Operation Temperature | 0℃~40℃(32℉ ~104℉) |
| Operating Humidity | 10% ~ 90% (Non-condensing) |
| Storage Humidity | 5% ~ 90% (Non-condensing) |
| Package Contents | AX1500 Dualband Wi-Fi 6 Gigabit VDSL Modem Router*1 External Splitter*1 Power Adapter*1 RJ11 DSL Cable*2 RJ45 Ethernet Cable*1 Quick Installation Guide*1 |
