AC3  Wireless AC750 Easy Setup Router

Wireless AC750 Easy Setup Router

Tenda AC3 is a wireless AC750 Easy Setup Router specially designed for small & medium house. 3*5dBi high-gain omnidirectional antennas boost Wi-Fi throughout your house to enjoy ultimate surfing fun. Powerful dual-core 1 GHz CPU, it ensures exceptional and smooth wireless performance, making it ideal for streaming HD video, making VolP and online gaming. Easy setup makes you can enjoy fluid Wi-Fi effortlessly.
Explore
AC3AC3AC3AC3
Documents
AC3 Quick Installation GuideAC3 Quick Installation Guide
AC3 Web User GuideAC3 Web User Guide
AC3 DatasheetAC3 Datasheet
Symbols on Products and MaterialsSymbols on Products and Materials
Datasheet
You can click here to export the current parameters (.docx)
Standard&ProtocolIEEE802.3, IEEE802.3u
Interfaces4*10/100Mbps WAN/LAN ports
Antenna3*external antennas
Button1*Wps/Reset button
PowerInput: AC 100-240V~50/60Hz
Output: DC 12V⎓ 1A
Dimension185.6*118.4*31.2mm
LED Indicator1*LED
Wireless StandardIEEE 802.11ac wave2/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
Data Rate5 GHz: 433 Mbps
2.4 GHz: 300 Mbps
Frequency2.4G: 2412-2472MHz(CH1-CH13)
5G: 5150-5350MHz(CH36-CH64)
5725-5850MHz(CH149-CH165)
Transmission PowerCE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)
Basic FeaturesCE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)
Wireless SecurityWPA/WPA2,WPS
Wireless Security: Enable /Disable
Internet Connection TypePPPoE, Dynamic IP, Static IP
Operating ModeRouter Mode
AP Mode
Universal Repeater Mode（Client+AP,WISP）
DHCP ServerDHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Allocation
Virtual ServerPort Forwarding
FirewallBlock Ping From WAN
UDP Flood Attack Defense
TCP Flood Attack Defense
ICMP Flood Attack Defense
DDNSDynDNS, no-ip, oray, 88ip
VPNIPSec Transparent Transmission
PPTP Transparent Transmission
L2TP Transparent Transmission
PPTP VPN Server
PPTP VPN Client
L2TP VPN Client
Special FeaturesPPPoE Username/Password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED on/off
Tenda Cloud
Tenda WiFi App
OthersBroadband management
MAC address clone
System Log
Backup & Restore configurations
Online Upgrade
IPv6
TemperatureOperating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃
HumidityOperating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing
CertificationOperating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing
EIRP Power (Max)CE, FCC, RoHS
Package ContentsNetwork Cable*1
Power Adapter*1
Wi-Fi Router *1
Quick Installation Guide*1
