Network standards

IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x standards.

LED Indicator

18*Link/Act
1*Power

Interfaces

16*10/100/1000 Base-T Ethernet ports (Data/Power)
2*10/100/1000 Base-T Ethernet ports (Data)

Transmission media

Recommended: CAT5/5e UTP or better

Fan quantity

Dimension

294*120*44mm

Level of protection

Port: 4 KV

Forwarding mode

Store-and-forward

Switch capacity

36Gbps

Packet forwarding rate

26.8Mpps

Buffer

4Mb

MAC address table

Jumbo frame

PoE budget

Single port: AF: 15.4W, AT: 30W
Whole device: 140W

Power consumption

150W

Input voltage

190－240V～ 50/60Hz

Mounting

Rack mounting : support
Desktop mounting: support
Wall mounting: support

Environment

Operating temperature：0°C - 45℃
Storage temperature：-40°C - 70°C
Operating humidity：10% - 90%,non-condensing
Storage humidity：5% - 90%,non-condensing

Certification
