Network standards

IEEE802.3、IEEE802.3u

LED Indicator

Link/Act , PoE Status

Interfaces

1*10/100 Base-TX Ethernet ports(Data/PoE)
1*10/100 Base-TX Ethernet ports(Data)

Transmission media

Recommended: CAT5/5e UTP or better

Dimension

84.5mm*44mm*29.8 mm

Level of protection

ESD:
Air discharge: ±10kV
Contact discharge: ±8kV

Forwarding mode

Store-and-forward

Transmission Rate

100Mbps

PoE budget

Single port: AF: 15.4W
Whole device: 15W

Power consumption

15W

Input voltage

100－240V AC 50/60Hz
48V/0.3A DC（Power Adapter Output）

Mounting

Desktop mounting: support

Environment

Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

FCC、CE、RoHS
