1*10/100/1000Mbps RJ45

2*5dBi dual-band antennas

1 * WPS Button
1 * Reset Button

1 * Signal LED

72*47.5*210mm(L x W x H)

IEEE802.11b,IEEE 802.11g, IEEE 802.11n, IEEE 802.11a,IEEE 802.11ac, IEEE802.11ax

5 GHz(11ax)
2.4 GHz

2.4 GHz
11b-1M:-96.5dBm
11g-54M:-78.5dBm
11n-20M-MCS7:-76.5dBm
11n-40M-MCS7:-72dBm
5 GHz:
11a-6M:-95dBm
11n-20M-MCS7:-76dBm
11n-40M-MCS7:-72.5dBm
11ac-80M-MCS9:-63.5dBm
11ax-80M-MCS11：-60.5dBm

2.4GHz ≤ 20dBm
5GHz≤23dBm

Repeater Mode, Access Point Mode

WPA2-PSK
WPA3-SAE/WPA2-PSK
Wireless Encryption Disable and Enable

FCC CE SRRC ROSH UCCA

CN
US
EU
UK
AU
BR

1 * Dual-Band Wi-Fi 6 Range Extender
1 * Quick Installation Guide

Online upgrade, LED Indicator Control, DST, Factory Settings, Login Password and Reboot

Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: (10~90)
% RH, non-condensing
Storage Humidity: (5~90)
%RH, non-condensing
