IEEE 802, 802.1Q, 802.10, IEEE 802.11, 802.3U, 802.3Z

GPON: ITU G.984.1, ITU G.984.2, ITU G.984.3, ITU G.984.4
EPON: IEEE 802.3 ah

1*SC/APC or SC/UPC （optional）Port
4*1000Mbps RJ45 LAN Ports
1*DC Power

PWR, PON, LOS, LAN, WLAN

1 *RST/WPS Button

Class B+

Transmit at 1310nm, Receive at 1490nm

20km Max

EPON：Upstream 1.244Gbps Max, Downstream 1.244Gbps Max
GPON：Upstream 1.244Gbps Max, Downstream 2.488Gbps Max

220.8×141.9×31mm（L×W×H)

0.5~5dBm

-28~-8dBm

DC 12V /1.0A

≤12w

Server, Client, DHCP Client List, Address Reservation, DHCP Relay

PPPOE, Dynamic IP, Static IP, Bridge, Support Multiple WAN Connection

TR069, Internet, IPTV

Bandwidth Control

IPv4, IPv6

DHCP, Dynamic DNS , IGMP Proxy UPnP, MU-MIMO,QOS,Preset,Easymesh

PPTP, L2TP, IPsec Pass-through

ALG, IP Filter ,Port Filter, Mac Filter, URL Filter Port Forwarding，DMZ, DDOS

Radvd, Dhcpv6, MLD Proxy, MLD Snooping

Ping, Ping6, Tracert, Tracert6

ACS, Connection request

2.4GHz & 5GHz

2.4G:20M/40M
5G:20M/40M/80M

2.4G : CH1-CH13
5 G : CH36-CH48, CH149-CH165

4 * 6 dBi Antenna

WPS

11n 300M + 11ax 1201M

2.4G: <25.5 dBm(EIRP)
5G: <22.5dBm(EIRP)

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Beamforming,OFDMA, MU-MIMO

64/128-bit WEP, WPA / WPA2/ WPA3

Main SSID at 2.4Ghz and 5GHz
4 Guest SSIDs Both At 2.4GHz and 5GHz

32 at both 2.4GHz and 5GHz

0℃ ~ 45℃

-40℃ ~ 70℃

10% ~ 95% （Non-condensing）

5% ~ 90% (Non-condensing)

1*HG15C, 1* Power adapter, 1* User manual, 1* RJ45 cable

CE , RoHS，Anatel
