IEEE 802, 802.1Q, 802.10, IEEE 802.11, 802.3U, 802.3Z

GPON: ITU G.984.1, ITU G.984.2, ITU G.984.3, ITU G.984.4 EPON: IEEE802.3ah

1*SC/APC or SC/UPC （optional）Port
2*1000Mbps RJ45 LAN Ports
1*Power Port

PWR, PON, LOS, LAN,2.4G,5G

1*WPS/RST Button

Class B+

Transmit at 1310nm, Receive at 1490nm

20km Max

EPON：Upstream 1.25Gbps Max, Downstream 1.25Gbps Max
GPON：Upstream 1.25Gbps Max, Downstream 2.5Gbps Max

164*116*27.5mm (W * D * H)

0.5~5dBm

-28~-8dBm

DC 12V /1A

≤12w

Server, Client, DHCP Client List, Address Reservation, DHCP Relay

PPPOE, Dynamic IP, Static IP, Bridge, Support Multiple WAN Connection

TR069, Internet, IPTV

IPv4, IPv6

DHCP
Dynamic DNS
IGMP Proxy
UPnP

PPTP, L2TP, IPsec Pass-through

ALG, IP Filter ,Port Filter, Mac Filter, URL Filter Port Forwarding，DMZ

Radvd, Dhcpv6, MLD Proxy, MLD Snooping

Ping, Ping6, Tracert, Tracert6

ACS, Connection request

2.4GHz & 5GHz

EPON：Upstream 1.25Gbps Max, Downstream 1.25Gbps Max

2.4G : CH1-CH13
5G : CH36-CH64, CH100-CH140, CH149-CH165

2 * 5 dBi Antenna

WPS

11n 300M + 11ac 867M

2.4G: <20 dBm(EIRP)
5G: <23dBm(EIRP)

Enable/Disable Wireless Radio, WDS Bridge, WMM,

64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK Encryption, Wireless

Main SSID at 2.4Ghz and 5GHz

32 at both 2.4GHz and 5GHz

0°c ~ 45°c

-40°c ~ 70°c

10% ~ 90% （Non-condensing）

5% ~ 90% (Non-condensing)

1*HG7c, 1* Power adapter, 1* User Manual, 1* RJ45 cable

CE, FCC , Anatel, RoHS
