IEEE802.3，IEEE802.3u，IEEE802.3ab

Dual-core 1GHz

64MB

1*10/100/1000Mbps WAN port
2*10/100/1000Mbps LAN ports

4*6dbi external antennas

1*WPS/Reset button

Input：AC 100-240V—50/60Hz
Output：DC 12V 1A

Sys*1

200*127*33.6mm

IEEE 802.11ac/a/n @5GHz
IEEE 802.11b/g/n @2.4GHz

5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps

CE:
2.4G: 2412-2472MHz(CH1-CH13)
5G: 5150-5250MHz(CH36-CH64)
FCC:
2.4G: 2412-2462MHz(CH1-CH11)
5G: 5150-5250MHz(CH36-CH64)
5725-5825MHz(CH149-CH165)

CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)

WPA2-PSK
Wireless Security : Enable /Disable

PPPoE, Dynamic IP, Static IP
Support automatic access detection
Supports broadband account automatic transfer

IPv4&IPv6

Router Mode
AP Mode
Universal Repeater Mode（Client+AP,WISP）

Client Filter
URL Filter
Time Limit

DHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Allocation

Port Forwarding, DMZ Host, UPnP

ICMP Flood Attack Defense
TCP Flood Attack Defense
UDP Flood Attack Defense
Block Ping From WAN

Support DynDNS, 88ip，no-ip

IPsec pass through
PPTP pass through
L2TP pass through

Guest Network
IPTV
Signal Adjustment
IPv6

PPPoE Username/password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED on/off
Tenda App
Dual-band in One
IPv6 Features Supported
Broadband management
MAC address clone
Backup & Restore configurations
Firmware upgrade from local

Operating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃

Operating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing

CE, FCC,RoHS

Wi-Fi Router *1
RJ45 Ethernet Cable*1
Power Adapter*1
Quick Installation Guide*1
