IEEE802.3, IEEE802.3u,IEEE802.3ab

1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports

4*6dBi external antennas

1* WPS，1*Reset button

Input：AC 100-240V~50/60Hz 0.6A
Output：DC 12V⎓1.5A

SYS*1

272.44x162.85x43.71mm

IEEE 802.11ac/a/n/ax 5GHz
IEEE 802.11b/g/n/ax 2.4GHz

5GHz: Up to 2402Mbps
2.4GHz: Up to 574Mbps

Simultaneous dual band 2.4 & 5GHz

CE:
<20dBm(2.4G)
<23dBm(5G)

SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
MU-MIMO
Support signal strength adjustment

WPA-PSK,WPA2-PSK, WPA/WPA2-PSK
WPA3-SAE/WPA2-PSK
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up)
fast encryption

PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia)
L2TP(Russia),Unifi,Maxis,Maxis-special,Manual

Wireless Router Mode
Universal Repeater Mode

DHCP Server
DHCP Client List
DHCP Reservation

Port Forwarding
DMZ Host
UPnP

Forbid UDP flood attack
Forbid TCP flood attack
Forbid ICMP attack
Forbid WAN PING from internet

Support DynDNS, No-ip

PPTP server
PPTP client
L2TP client

WPA3
Dual-band
Wireless Signal Adjustment
Wi-Fi Timer Switch
Smart Power Saving
Panel LED Switch
Tenda App: Local and Remote Management

Bandwidth Control
Guest Network
IPTV
VLAN
MAC Clone
Static Routing
System Log
Backup & Restore configurations
Firmware upgrade online
Firmware upgradeable via browser
Supports IPv6

Operating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃

Operating Humidity : 10 %~90% RH non-condensingStorage Humidity : 5 %~ 90%RH non-condensing

CE, RoHS, FCC

Wireles Router*1
Power Adapter *1
Install Guide*1
Ethernet Cable*1
