5G03
Hardware Specifications
Processor
7nm, Quad cores,core frequency 2 GHz
Cellular Technologies
5G/4G/3G Multi-Mode, 5G NR SA/NSA, 4G FDD/TDD LTE, 3G WCDMA
5G NR 3GPP
Release 15
5G NR Peak Download Speed
4.67 Gbps
5G NR Peak Upload Speed
1.25 Gbps
NR Frequency Band
5G NR (Bands n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78)
FDD-LTE (Bands 1, 3, 5, 7, 8, 20, 28, 32)
TD-LTE (Bands 38, 40, 41, 42, 43)
WCDMA (850, 900, 2100 MHz)
5G NR Download MIMO
SISO,2*2,4*4
5G NR Upload MIMO
SISO,2*2
5G NR Download Modulation
QPSK, 16QAM,64QAM,256QAM
5G NR Upload Modulation
QPSK, 16QAM,64QAM,256QAM
Wireless Connectivity
Wi-Fi 6 (802.11ax) with 2x2 MIMO
Wi-Fi speed
574Mbps on 2.4 GHz
1201Mbps on 5 GHz
Wi-Fi standards
802.11b/g/n,802.11ac,802.11AX
Wi-Fi frequency
2.4GHz,5GHz
Wi-Fi transmit Power
2.4GHz:up to 20dBm
5GHz: up to 23dBm
Ethernet Ports
1 × 10/100/1000 Mbps LAN/WAN Port
1 × 10/100/1000 Mbps LAN Port
SIM Card
1*Nano SIM(4FF)
Button
1× Power on/off
1× RST hole
1×MESH/WPS
Antennas and Ports
8 × Internal 5G/4G Antennas
2 × Internal Wi-Fi Antennas
2 × TS-9 antennas ports
Software Specifications
WAN Type
4G/5G or Wired
5G/4G Features
Auto-APN
5G SA/NSA dual mode
Auto dial-up
5G Location optimization
5G/4G E-UTRAN New Radio–Dual Connectivity
Roaming
SMS(Send/Receive/Delete)
USSD
Data limted
PIN Management
Wi-Fi functions
Broadcast and Hide Wi-Fi name
Priority 5GHz Wi-Fi
Guest network
Wi-Fi schedule
OFDMA
MU-MIMO
Wi-Fi security
WPA2/WPA3,WPA/WPA2,WPA2-PSK,WPA-PSK,WEP
Software features
EasyMesh
Parental control
DHCP(DHCP Server and Client)
Virtual Server(UPnP/DMZ/Port Forwarding)
DDNS(DynDns, 88ip)
VPN(PPTP Client/L2TP Client/PPTP Server/IPSEC)
Firewall
QOS
Upgrade firmware from local or OTA
Certifications
Certifications
FCC Granted
CE Granted
ROHS Granted
Working Environment
Temperature
Operating Temperature: 0℃~40℃
Storage Temperature: -30ºC~70ºC
Humidity
Operating Humidity: 10% ~ 90% RH Non-condensing
Storage Humidity: 5% ~ 90% RH Non-condensing
Package lists
Contents
1 * 5G NR Router
1 * Ethernet cable
1 * Power adapter
1 * User Guide
