End of Life

AC6  AC1200 Smart Dual-Band WiFi Router

AC1200 Smart Dual-Band WiFi Router

Datasheet
Standard&ProtocolIEEE802.3, IEEE802.3u
Interfaces1*10/100Mbps WAN port
3*10/100Mbps LAN ports
Antenna4*5dBi external antennas
Button1*WiFi on/off, 1* Reset/WPS button
PowerInput:100-240V—50/60Hz, 0.2A
Output:DC 9V1A
Dimension220mm*141.5mm*49mm(L*W*H)
LED IndicatorSYS*1,WAN*1, LAN*1, 2.4G*1, 5G*1,WPS*1
Wireless StandardIEEE 802.11ac/a/n @5GHz
IEEE 802.11b/g/n @2.4GHz
Data Rate5GHz: 867Mbps
2.4GHz: 300Mbps
FrequencySimultaneous dual band 2.4 & 5GHz
Transmission PowerCE:
<20dBm(2.4G)
<23dBm(5G)
FCC:
<30dBm
Basic FeaturesSSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
MU-MIMO
Wireless SecurityWPA-PSK/WPA2-PSK, WPA/WPA2
 Wireless Security: Enable/Disable
 WPS(WiFi Protected Set-up) fast encryption
Internet Connection TypePPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating ModeWireless Router Mode
Universal Repeater Mode
WISP Mode
DHCP ServerWireless Router Mode
Universal Repeater Mode
WISP Mode
Virtual ServerPort Forwarding
DMZ Host
UPnP
SecurityClient Filter
Parental Control(support black list and white list)
Remote Web Management
FirewallForbid UDP flood attack
Forbid TCP flood attack
Forbid flood attack
Forbid WAN PING from internet
DDNSSupport DynDNS, Oray.com, 88ip
VPNIPsec pass through
PPTP pass through
L2TP pass through
PPTP client
L2TP client
Special FeaturesPPPoE Username/password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED on/off
Tenda Cloud
Tenda App
OthersBandwidth Control
Guest Network
IPTV
MAC Clone
System Log
Backup & Restore configurations
Firmware upgrade online
Firmware upgradeable via browser
Supports IPv6
TemperatureOperating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.
HumidityOperating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Default SettingsDefault Access: tendawifi.com or //192.168.0.1
CertificationCE/FCC/RoHS
EIRP Power (Max)2.400-2.4835GHz: 19.95dBm (EIRP)
5.150-5.250GHz: 22.90dBm (EIRP)
Package ContentsAC1200 Smart Dual-Band WiFi Router
Power Adapter
Install Guide
Ethernet Cable
