Galeria
AC10
Sprzęt komputerowy
Standardowy i protokół
IEEE 802.3, IEEE 802.3u
Interfejsy
3*GE LAN Ports
1*GE WAN Port
Antena
4*5dBi External Dual Band Antennas
Przycisk
1*WiFi On/Off button
1*Reset/WPS button
Moc
Power Input: 100-240V—50/60Hz
Power Output: DC 12V==2A
Wymiar
Package Box: 390*198*70mm(L*W*H)
Device: 220*141.5*49mm(L*W*H)
Wskaźnik ledowy
1*WAN、1*LAN、1*Wi-Fi/WPS、1*SYS
Bezprzewodowy
Standard bezprzewodowy
IEEE 802.11ac/n/a 5GHz
IEEE 802.11n/g/b 2.4GHz
Szybkość przesyłania danych
5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps
Częstotliwość
Simultaneous dual band 2.4 & 5GHz
Moc transmisji
CE:
<20dBm (2.4G)
<23dBm (5G)
FCC:<30dBm
Podstawowe funkcje
MU-MIMO
SSID Broadcast and Hide
Beamforming
Signal Power Adjustment
Ochrona bezprzewodowa
WPA-PSK, WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS Fast Encryption
Oprogramowanie
Typ połączenia internetowego
Dynamic IP/Static IP/PPPoE
Connection Type Auto Detection
Broadband Account and Password Migration
Tryb pracy
Router/AP/Universal Repeater/WISP
DHCP serwer
DHCP Server and Client
DHCP Client List
DHCP Address Reservation
Wirtualny serwer
UPnP
DMZ Host
Port Forwarding
Bezpieczeństwo
Local Management
Remote Management
Tenda APP
Zapora
Forbid UDP Flood Attack
Forbid TCP Flood Attack
Forbid ICMP Flood Attack
Forbid WAN Ping from Internet
PPTP Pass Through
L2TP Pass Through
IPSec Pass Through
DDNS
DynDns, NO-IP, Oray.com, 3322.org, 88ip
VPN
PPTP Client
PPTP Server
L2TP Client
Cechy szczególne
Smart Wi-Fi Schedule
Smart Power Saving
Smart LED On/Off
Inni
IPv6 Features Supported
Bandwidth Control
MAC Address Filter
IP and MAC Address Binding
IPTV
Black/White List
MAC Clone
Static Routing
System Log
Network Time
Backup/Restore Settings
System Upgrade Online
Inni
Temperatura
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.
Wilgotność
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Ustawienia domyślne
Default Access: tendawifi.com or http://192.168.0.1
Orzecznictwo
CE, FCC, RoHS, BSMI, NCC, EAC, IC
Moc EIRP (maks.)
Zawartość Paczki
AC1200 Smart Dual-Band Gigabit WiFi Router
Power Supply
Ethernet Cable
Quick Installation Guide
