IEEE 802.3, IEEE 802.3u, IEEE 802.3ab，IEEE 802.3z，IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.1d, IEEE 802.1w IEEE802.3af/at

24 * Link/Act LEDs
1 * G1 LED
1 * G2/SFP2 LED
1 * PoE-MAX LED
1 * Power LED
1 * SYS LED

24 * 10/100 Base-TX Ethernet ports (Data/Power)
2 * 10/100/1000 Base-T Ethernet ports (Data)
1 * 1000 Base-X SFP port (Combo)

Recommended: CAT5/5e UTP or better

2

Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV

Store-and-forward

8.8 Gbps

6.55Mpps

4Mb

16K

Support

Single port: AF: 15.4W, AT: 30W
Whole device: 410W

100-240V AC 50/60Hz

410W output the whole device

440.0mmx284.0mmx44.0mm

Desktop mounting: support
Wall mounting: support
Rack mounting:non-support

Support

Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)
RH, non-condensing
Storage humidity: (5% - 90%)
RH, non-condensing

FCC、CE、RoHS

Support over temperature protection for PoE module Support graphical management detection of PD equipment

MAC-Port Binding

Supports Port VLAN Supports 802.1Q VLAN

Static Trunk Supports 3 groups of 4-Port trunk support

STP/RSTP

IGMP (v1/v2)
Snooping

N: 1 port mirroring

802.1p and DSCP priority re-marking Flow control Flexible queue scheduling algorithm can be set based on port and queue, support SP, WRR

Support SNMP v1/v2 and WEB-based management
