IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x,IEEE802.1p, IEEE802.1q, IEEE802.1w, IEEE802.3af/at

16 * Link/Act LEDs

1 * G1 LED

1 * G2/SFP2 LED

1 * PoE-MAX LED

1 * Power LED

1 * SYS LED

16 * 10/100 Base-TX Ethernet ports (Data/Power)

2 * 10/100/1000 Base-T Ethernet ports (Data)

1 * 10/100/1000 Base-X SFP port (Combo)

Recommended: CAT5/5e UTP or better

1

Lightning protection for ports: 6kV

Lightning protection for power: 6kV

ESD:

Air discharge: ±10kV

Contact discharge: ±8kV

Store-and-forward

7.2 Gbps

5.36Mpps

1.25Mb

4K

N/A

Support

Single port: AF: 15.4W, AT: 30W

Whole device: 230W

100-240V AC 50/60Hz

250W output the whole device

440.0mmx178.8mmx44.0mm

Desktop mounting: support

Wall mounting: support

Rack mounting:non-support

Support

Operating temperature: 0°C - 45℃

Storage temperature: -40°C - 70°C

Operating humidity: (10% - 90%)

RH, non-condensing

Storage humidity: (5% - 90%)

RH, non-condensing

FCC、CE、RoHS

N/A

Support over temperature protection for PoE module Support graphical management detection of PD equipment

MAC-Port Binding

Supports Port VLAN Supports 802.1Q VLAN

N/A

Static Trunk Supports 3 groups of 4-Port trunk support

STP/RSTP

IGMP (v1/v2)

Snooping

N: 1 port mirroring

802.1p and DSCP priority re-marking Flow control Flexible queue scheduling algorithm can be set based on port and queue, support SP, WRR

N/A

N/A

Support SNMP v1/v2 and WEB-based management
