IEEE 802.3、 IEEE 802.3u、IEEE 802.3ab、IEEE 802.3x、 IEEE 802.3af、IEEE 802.3at

9* Link/Ack LED indicators

1 * Power LED indicator

8*10/100/1000 Base-T Ethernet Ports(Data/Power)

1*10/100/1000 Base-T Ethernet Ports(Data)

Recommended: CAT5/5e UTP or better

N/A

177.5mmx104.0mmx26.0mm

Lightning protection for ports: 6kV

Lightning protection for power: 6kV

ESD:

Air discharge: ±10kV

Contact discharge: ±8kV

Store-and-forward

18 Gbps

13.4Mpps

2M

16K

N/A

Single port: AF: 15.4W, AT: 30W

Whole device: 92W

/

100-240V AC 50/60Hz

51V /2.0A DC（Power Adapter Output ）

Desktop mounting: support

Wall mounting: support

Rack mounting:non-support

Operating Temperature: 0℃~45℃

Storage Temperature: -40℃~70℃

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

FCC、CE、RoHS

Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.

VLAN: ports 1 to 8 are isolated from each other, but can communicate with ports 9 (uplink port)

respectively.
