W9

11AC 1200Mbps Wireless In-Wall Access Point

W9

w9

What it does

W9 is designed to provide wifi coverage for hotel rooms,villa,university dormitories, hospital wards, and other sites with densely divided rooms. It delivers 867Mbps wireless rate at 5GHz radio and 300Mbps wireless rate at 2.4GHz radio with the latest Wi-Fi 802.11ac technology. Adopt of 86 Type wall mount junction box design, it can blend into existing decoration perferctly without any damage.Compliant with PoE 802.3af standard enable it to be deployed quickly.

Main Features

  • *  Dual band 11AC 1167Mbps
  • *  Two 10/100Mbps LAN port
  • *  Compliant with PoE 802.3af
  • *  VLAN tagging for multi SSID
  • *  Centralized managed by M3
  • *  86 Type wall mount junction box design

Dual band 11AC 1167Mbps

W9 delivers 867Mbps wireless rate at 5GHz radio and 300Mbps wireless rate at 2.4GHz radio with the latest Wi-Fi 802.11ac technology. The outstanding Wi-Fi performance is ideal for bandwidth sensitive applications like streaming in HD and seamless online gaming

2.4GHZ
5GHZ
w9

86 Type wall mount junction box design

W9 adopts of 86 type wall mount junction box design to deploy into the existing wall jack.It will pose no problem to neighbourhood panels or other decorations.

w9
W6-S

Compliant with PoE 802.3af

The port on the back panel support Power over Ethernet (PoE) functionality, which allows both power and data to be carried over a single Ethernet cable to W9.It is easy to deploy without additional power supply.

Advanced Wireless Security

W9 offers multi mechanism to prevent unauthenticated access and protect data privacy.

*   64/128bit WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
*   Wireless Access Controll based on the mac address of wireless adapter
*   Client Isolation and SSID isolation

W6-S

VLAN Tagging For Multi SSID

W9 can be configured to broadcast up to twelve SSID. Each SSID can be tagged to a specified network VLAN to establish different internet access rights.

W6-S

Easy to setup, Easy to manage

W9 can be managed by AP Controller, the administrator can setup, manage and monitor all the Aps online status more easily.
